Compare Wall Products

Download PDF

WiggleRoom Products

On this page you'll find a comparison of our demountable partition systems.

View WiggleRoom product comparison here.

WiggleRoom Products

On this page you'll find a comparison of our demountable partition systems.

View WiggleRoom product comparison here.
Download PDF
Overview
Key Features

Key Features

  • Passive aesthetics with seamless reveal lines (nearly matches appearance of drywall)
  • Modular construction and easily reconfigurable
  • Quiet acoustics with STC rating of 50
  • Paint it, wrap it, inkjet print on it

Key Features

  • Supports custom designs and configurations
  • Compatible with system furniture and other architectural solutions
  • Panel shells available in solid materials, glass or combination
  • Seamlessly delivers power and data options
  • Soft close/open sliding doors

Key Features

  • Highly adaptable alternative to traditional stick-built storefront
  • Requires 50% less labor than stick-built construction
  • Pre-assembled at KI manufacturing site
  • Leaves no waste, saving time, money and environmental resources
  • Soft close/opening sliding doors
Ease of Installation & Reconfiguration

Ease of Installation & Reconfiguration

Easy. On average, installation rate of one hour per lineal foot.

Ease of Installation & Reconfiguration

Easy. On average, installation rate of one hour per lineal foot.

Ease of Installation & Reconfiguration

Easy. On average, installation rate of one hour per lineal foot.

Unitized vs. Stick-Built

Unitized vs. Stick-Built

Unitized

Unitized vs. Stick-Built

Both

Unitized vs. Stick-Built

Both

Lead Times

Lead Times

8-10 Weeks

Lead Times

Non-Wood

  • 8-10 Weeks

Wood

  • 10 Weeks

Lead Times

8-10 Weeks

Warranty

Warranty

10 years

Warranty

10 years

Warranty

10 years

Fit & Finish Options
Double Glazed

Double Glazed



Double Glazed

Yes

Double Glazed



Single Glazed

Single Glazed

Yes

(clerestory)

Single Glazed

Yes

Single Glazed

Yes

Door Types

Door Types

Yes

*Uses Genius doors

Door Types

  • Sliding
  • Pivot
  • Butt-hinge

Door Types

  • Sliding
  • Pivot
  • Hydraulic hinge
Finishes - Solid Panels

Finishes - Solid Panels

  • Painted steel
  • Inkjet print

Finishes - Solid Panels

  • Painted steel
  • Fabric
  • Laminate
  • Tackable
  • Veneer

Finishes - Solid Panels



Finishes - Trim

Finishes - Trim

  • Anodized Aluminum
  • Over 40 standard paint finishes and ability to custom match

Finishes - Trim

  • Anodized Aluminum
  • Over 40 standard paint finishes and ability to custom match

Finishes - Trim

  • Anodized Aluminum
  • Over 40 standard paint finishes and ability to custom match
Panel Enhancements

Panel Enhancements

  • Markerboard
  • Magnetic
  • Integrated Multimedia

Panel Enhancements

  • Veneers
  • Markerboard
  • Magnetic
  • Integrated Multimedia
  • Lighting

Panel Enhancements

Glass Only

Electrical Options

Electrical Options

  • Panel Only
  • Conventional & Pre-wired

Electrical Options

  • Panel & Base
  • Conventional & Pre-wired

Electrical Options



Dimensions
Height & Width

Height & Width

  • Panel sizes in 1/8" increments
  • W6–48"
  • H84–120"

*Stackable up to 144"

Height & Width

  • Panel sizes in 1/8" increments
  • W6–60"
  • H84–120"

*Stackable up to 144"

Height & Width

  • Panel sizes in 1/8" increments
  • W12–48"
  • H84–120"
Panel Thickness

Panel Thickness

3.5"

Panel Thickness

3.5"

Panel Thickness

2.25"

Glass Thickness, Tempered and Laminate

Glass Thickness, Tempered and Laminate

  • 1/4"
  • 3/8"
  • 1/2"

(no full-height glass panels)

Glass Thickness, Tempered and Laminate

  • 1/4"
  • 3/8"

Glass Thickness, Tempered and Laminate

  • 1/2"
Standard Base Height Option Sizes

Standard Base Height Option Sizes

4.00"

Standard Base Height Option Sizes

  • 0.75" (flush)
  • 1.00" (recessed)
  • 4.00"
  • 5.00"

Standard Base Height Option Sizes

  • 1"
  • 3.25"
  • 4.00"
Non-standard Flush Base Height Option Size

Non-standard Flush Base Height Option Size



Non-standard Flush Base Height Option Size

2.125"

Non-standard Flush Base Height Option Size



Base & Ceiling Channel Adjustability Range

Base & Ceiling Channel Adjustability Range

  • Ceiling +/- 3/8"
  • Base +/- 1"

Base & Ceiling Channel Adjustability Range

  • 4" & 5" Base +/- 1"
  • Ceiling +/- 1/2"
  • Flush & Recessed base +/-.5"

Base & Ceiling Channel Adjustability Range

  • Base 1" +3/8", Ceiling +/- 0"
  • Base 3.25" +1", Ceiling +/- 0"
  • Base 4.00" +1.75", Ceiling +/- 0"

*Cannot adjust down

Testing & Compliance
STC/NRC Range

STC/NRC Range

  • 50 STC
  • Solid Panel
  • Available Acoustic Flyover 0.9 NRC

STC/NRC Range

  • 44-48 STC
  • Solid Panel
  • Acoustic Flyover 0.9 NRC

STC/NRC Range

  • 36 STC 1/2" Tempered Glass
  • 38 STC 1/2" Laminated Glass
  • 39 STC 1/2" Laminated Glass w/ Acoustic Interlayer
Fire Rating

Fire Rating

Similar to all movable wall systems, KI architectural wall is not a fire reated wall.  In order for an Architectural Wall to be fire rated, it needs to extend to the building deck above. The surface materials for KI walls are tested for flame spread and smoke development per ASTM E84.

Fire Rating

Similar to all movable wall systems, KI architectural wall is not a fire reated wall.  In order for an Architectural Wall to be fire rated, it needs to extend to the building deck above. The surface materials for KI walls are tested for flame spread and smoke development per ASTM E84.

Fire Rating

Similar to all movable wall systems, KI architectural wall is not a fire reated wall.  In order for an Architectural Wall to be fire rated, it needs to extend to the building deck above. The surface materials for KI walls are tested for flame spread and smoke development per ASTM E84.

SCS Indoor Advantage Gold

SCS Indoor Advantage Gold

Yes

SCS Indoor Advantage Gold

Yes

SCS Indoor Advantage Gold

Yes

Carb

Carb

Yes

Carb

Yes

Carb

Yes

FSC Certified

FSC Certified



FSC Certified

Yes

FSC Certified



BIFMA Level 2

BIFMA Level 2

Yes

BIFMA Level 2

Yes

BIFMA Level 2

Yes

Healthier Hospital Initiative

Healthier Hospital Initiative

Yes

Healthier Hospital Initiative

Yes

Healthier Hospital Initiative

Yes

EPD Verified

EPD Verified

Yes

EPD Verified

Yes

EPD Verified

Yes

Recycled Content

Recycled Content

Yes

(over 30%)

Recycled Content

Yes

(over 30%)

Recycled Content

Yes

(over 60%)

Seismic

Seismic

Yes

*Compatible in seismic design categories A-F

Seismic

Yes

*Compatible in seismic design categories A-F

Seismic

Yes

*Compatible in seismic design categories A-F

ICC Compliant

ICC Compliant

No, structural calculations provided upon request

ICC Compliant

Yes

ICC Compliant

Yes

OSHPD Compliant

OSHPD Compliant



*Structural calculations provided upon request

OSHPD Compliant

Yes

OSHPD Compliant

Yes

Ordering
Location of Manufacturing

Location of Manufacturing

Manitowoc, Wisconsin

Location of Manufacturing

Manitowoc, Wisconsin

Location of Manufacturing

Manitowoc, Wisconsin

Approved Dealers

Approved Dealers

Open Line

Approved Dealers

Open Line

Approved Dealers

Open Line
